Compression & Hot-Press Molding

Large-format, thick-section and composite-reinforced parts — compression molding with a 500T four-column hydraulic hot press.

Process Overview

Compression Molding — When a Part Is Too Large for Injection

Compression molding applies heat and pressure to a pre-placed charge of material in an open mold, forcing it to fill complex cavities in one controlled stroke.

Compression molding with 500T hydraulic hot press
500T Hydraulic Hot Press

Large-Format & Thick-Section Capability

Our 500T four-column hydraulic hot press handles large-format and thick-walled parts that exceed the limits of conventional injection molding — ideal for CF-PEEK composite laminates, plates and structural profiles.

  • 500T four-column hydraulic hot press
  • Large-format and thick-section parts beyond injection limits
  • Excellent for CF-PEEK composite and laminate molding
  • High dimensional and density consistency
Why Compression Molding

Key Advantages

How compression molding delivers for demanding applications.

Large Format

Parts and plates beyond the platen limits of injection molding.

Thick Wall

Thick cross-sections molded consistently without sink or voids.

Composite-Ready

Ideal for CF-PEEK and fiber-reinforced laminate molding.

Consistency

High dimensional and density repeatability part to part.

Applications

Typical Compression-Molded Parts

Where compression molding is the right choice.

Large PEEK sealing components

Large Sealing Components

Big-diameter seals and rings that need full cross-section integrity.

CF-PEEK composite plates

CF-PEEK Composite Plates

Reinforced laminates and structural composite plates.

Thick-wall PEEK bearings

Thick-Wall Bearings

Heavy-section bearing and wear parts in PEEK and PI.

Explore Other Processes

One Roof, Four Processes

See how our other manufacturing lines can deliver your part.

Need a Large or Composite Part?

Share your drawing and volume — we'll recommend the most cost-effective compression molding route.
